This book is more focusing on enhancement of using Codes, Standards and Engineering Standards for
calculations, analysis and failure assessment rather than discussion of the basic theory in very details. Therefore,
this book is written based on thematic method where the subjects discussed in this book are frequently found in
working environment both in the oil/gas engineering consultant and operating companies.
This book has intended to assist engineers and designers and for the one who interested in mechanical static
and piping in doing their work and able to deliver the work which meets standard engineering practice.
The author prepared this book was based on gathered experiences during his tenure as a Piping / Mechanical
designer/engineer/lead engineer/principal engineer and business technical authority in the oil/gas industries both
in engineering consultant companies and in the oil/gas operating company in some countries such as Indonesia,
Brunei Darussalam and Malaysia.
The content of this book is comprised of basic theory and guideline, samples calculation and analysis, sample
design/drafting drawings and listed material properties tables for the following :
• Piping system component such as pressure drop, pipe size, pipe wall thickness under internal/external
and high pressures, piping flexibility, branch connection area replacement, hot tapping, simple stresses
benchmarking between manual and software calculations pipe stress analysis at elbow and pipe
expansion loop, pre-screening assessment for FIV and AIV, slug force at bend, WN flange stress analysis,
blinds and RO thickness, pipe class establishment, piping materials and safety factor, bolt torquing,
Relief valve reaction force, fillet weld strength, pipe support span, common and special pipe supports
and piping specialty item.
• Pipeline receiving facilities component such as pipeline wall thickness for oil and Gas services,
remaining strength of the corroded pipeline and pig tool load imposed at bend.
• Pressure vessel component such as shell and head thickness for circular and non-circular pressure vessels,
, vessel nozzle load and area replacement, vessel saddle supports, vessel base (bearing) plate and vessel
attachment. Rectangular storage tank wall thickness, nozzle load and stiffeners
• Temporary Repair for piping such as insert ring clamp, enclosure clamp and composite wrapping
